採用模組化電源迎接高功率航空航太與國防應用的挑戰
航空航太和國防市場繼續减小電源系統的尺寸和重量，同時要求滿足更大的功率
MIL-COTS DCM™ DC-DC 轉換器模組
堅固的高功率轉換器，適用於 28V 和 270V 輸入
DCM ChiP 是一款隔離穩壓 DC-DC 轉換器，可在未穩壓寬範圍輸入運行，以產生隔離輸出。憑藉其高頻零電壓開關（ZVS）拓撲結構，DCM 轉換器一直致力於為其各種輸入電壓範圍提供高效率。DCM 轉換器模組和下游負載點（PoL）產品支持高效配電，為一系列非穩壓電源到負載點提供卓越的電源系統性能和連接性。DCM 系列包括多種規格，支持 ±1% 精度的穩壓調節。採用 VIA 封裝的 DCM 模組可利用集成的 EMI 濾波、精確的穩壓輸出和 PM 母線控制介面（參考二次側地）提供更高級的功能。
篩選產品
0 個產品
Viewing
of
###
25
of
| 型號 | Datasheet | 輸入電壓 (V) | 輸出電壓 (V) | 功率 (W) | 控制介面 | 優化 | 安裝方式 | 溫度 | Dimensions mm | Dimensions in. | 封裝 | 加入購物車/查看詳情 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 3.3 (2.97 - 3.63) |
功率 (W): 120.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 3.3 (2.97 - 3.63) |
功率 (W): 120.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 5.0 (4.0 - 5.5) |
功率 (W): 180.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封裝: 3414 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 5.0 (4.0 - 5.5) |
功率 (W): 180.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 5.0 (4.0 - 5.5) |
功率 (W): 180.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 12.0 (7.2 - 13.2) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封裝: 3414 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 12.0 (7.2 - 13.2) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 12.0 (7.2 - 13.2) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 15.0 (9.0 - 16.5) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封裝: 3414 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 15.0 (9.0 - 16.5) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 15.0 (9.0 - 16.5) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 24.0 (14.4 - 26.4) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封裝: 3414 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 24.0 (14.4 - 26.4) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 24.0 (14.4 - 26.4) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 28.0 (16.8 - 30.8) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封裝: 3414 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 28.0 (22.0 - 30.8) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 28.0 (22.0 - 30.8) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 48.0 (28.8 - 52.8) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封裝: 3414 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 48.0 (28.8 - 52.8) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 28.0 (16.0 - 50.0) |
輸出電壓 (V): 48.0 (28.8 - 52.8) |
功率 (W): 320.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 3.3 (2.97 - 3.63) |
功率 (W): 80.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 3.3 (2.97 - 3.63) |
功率 (W): 80.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 5.0 (3.5 - 5.5) |
功率 (W): 80.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 5.0 (3.5 - 5.5) |
功率 (W): 80.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 12.0 (7.2 - 13.2) |
功率 (W): 60.0 |
控制介面: Analog |
優化: Array/
Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封裝: 2322 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 12.0 (7.2 - 13.2) |
功率 (W): 160.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 12.0 (7.2 - 13.2) |
功率 (W): 160.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 15.0 (9.0 - 16.5) |
功率 (W): 60.0 |
控制介面: Analog |
優化: Array/
Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封裝: 2322 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 15.0 (9.0 - 16.5) |
功率 (W): 160.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 15.0 (9.0 - 16.5) |
功率 (W): 160.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 24.0 (14.4 - 26.4) |
功率 (W): 60.0 |
控制介面: Analog |
優化: Array/
Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封裝: 2322 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 24.0 (14.4 - 26.4) |
功率 (W): 160.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 28.0 (16.8 - 30.8) |
功率 (W): 60.0 |
控制介面: Analog |
優化: Array/
Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封裝: 2322 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 28.0 (16.8 - 30.8) |
功率 (W): 160.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 28.0 (16.8 - 30.8) |
功率 (W): 160.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 48.0 (28.8 - 52.8) |
功率 (W): 60.0 |
控制介面: Analog |
優化: Array/
Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封裝: 2322 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 48.0 (28.8 - 52.8) |
功率 (W): 160.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 30.0 (9.0 - 50.0) |
輸出電壓 (V): 48.0 (28.8 - 52.8) |
功率 (W): 160.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封裝: 3623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 3.3 (2.97 - 3.63) |
功率 (W): 150.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 3.3 (2.97 - 3.63) |
功率 (W): 150.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 5.0 (4.0 - 5.5) |
功率 (W): 250.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封裝: 3714 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 5.0 (4.0 - 5.5) |
功率 (W): 250.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 5.0 (4.0 - 5.5) |
功率 (W): 250.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 12.0 (7.2 - 13.2) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封裝: 3714 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 12.0 (7.2 - 13.2) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 12.0 (7.2 - 13.2) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 15.0 (9.0 - 16.5) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封裝: 3714 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 15.0 (9.0 - 16.5) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 15.0 (9.0 - 16.5) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 24.0 (14.4 - 26.4) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封裝: 3714 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 24.0 (14.4 - 26.4) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 24.0 (14.4 - 26.4) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 28.0 (16.8 - 30.8) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Chassis Mount |
溫度: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封裝: 3714 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 28.0 (16.8 - 30.8) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 28.0 (16.8 - 30.8) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 28.0 (16.8 - 30.8) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 48.0 (28.8 - 52.8) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Standalone |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (160.0 - 420.0) |
輸出電壓 (V): 48.0 (28.8 - 52.8) |
功率 (W): 500.0 |
控制介面: Analog |
優化: Array |
安裝方式: Through Hole |
溫度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封裝: 4623 ChiP |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (180.0 - 400.0) |
輸出電壓 (V): 28.0 (22.0 - 36.0) |
功率 (W): 1300.0 |
控制介面: PM Bus |
優化: Array |
安裝方式: Chassis Mount |
溫度: -40 to 125°C |
Dimensions mm: 141.43 x 35.54 x 9.40mm |
Dimensions in.: 5.570 x 1.400 x 0.370in |
封裝: 5614 VIA |
View Details | ||
| 型號: | 輸入電壓 (V): 270.0 (180.0 - 400.0) |
輸出電壓 (V): 28.0 (22.0 - 36.0) |
功率 (W): 1300.0 |
控制介面: Analog |
優化: Array |
安裝方式: Chassis Mount |
溫度: -40 to 125°C |
Dimensions mm: 141.43 x 35.54 x 9.40mm |
Dimensions in.: 5.570 x 1.400 x 0.370in |
封裝: 5614 VIA |
View Details | ||
Power System Designer
採用電源系統設計工具快速查找產品Watch demo video
Output
Min output:
Minimum output:
Nom output:
Nominal output:
Max output:
Maximum output:
特性與優勢
特性與優勢
高達 1300W，46.4A 連續
高達 96% 峰值效率
功率密度高達 1032W/in3
OV、OC、UV、短路和熱保護
資源
Resources section
4623 ChiP
3714 VIA 3414 VIA 5614 VIA
- cURus – UL 60950-1, CSA 60950-1 »
- cTÜVus – EN 60950-1, UL 60950-1, CSA 60950-1
- CE 標示 – 低電壓指令 (2014/35/EC) 和 RoHS 修訂指令 (2011/65/EU)
- CB 認證 – IEC 60950-1
- cURus – UL 60950-1, CSA 60950-1 »
- cTÜVus – EN 60950-1, UL 60950-1, CSA 60950-1
- CE 標示 – 低電壓指令 (2014/65/EC) 和 RoHS 修訂指令 (2011/65/EU)
- CB 認證 – IEC 60950-1
3714 VIA 3414 VIA 5614 VIA
加州居民請參閱加州 65 號提案的內容
- 2322 ChiP 貫通孔產品 3D 模型圖
IGS STP - 3623 ChiP 貫通孔產品 3D 模型圖
IGS STP - 4623 ChiP 貫通孔產品 3D 模型圖
IGS STP - 3414 VIA DCM 帶通訊的底盤安裝外形圖
IGS STP - 3414 VIA DCM 帶通訊的貫通孔短引脚外形圖
IGS STP - 3414 VIA DCM 帶通訊的貫通孔長引脚外形圖
IGS STP - 3714 VIA DCM帶通訊的底盤安裝外形圖
IGS STP - 3714 VIA DCM 帶通訊的貫通孔短引脚外形圖
IGS STP - 3714 VIA DCM 帶通訊的貫通孔長引脚外形圖
IGS STP - 5614 VIA DCM 帶通訊的底盤安裝外形圖
IGS STP - 5614 VIA DCM 帶通訊的貫通孔短引脚外形圖
IGS STP - 5614 VIA DCM 帶通訊的貫通孔長引脚外形圖
IGS STP
Promo Component
在資源庫中查看更多檔案、影片和案例研究
