支持更多功能、增加有效载荷并延长运行时间
了解 Vicor 如何提供高效的大功率并减轻重量，支持更大的有效载荷，从而助力成功完成任务
MIL-COTS DCM™ DC-DC 转换器模块
坚固的高功率转换器，适用于 28V 和 270V 输入
DCM ChiP 是一款隔离稳压 DC-DC 转换器，可在未稳压宽范围输入运行，以产生隔离输出。DCM 转换器采用高频率零电压开关 （ZVS）拓扑，在指定输入线路范围内可实现高效率。DCM 模块转换器和下游负载点（PoL）产品支持高效配电，为一系列非稳压电源到负载点提供卓越的电源系统性能和连接性。DCM 系列包括多种规格，支持 ±1％ 精度的稳压调节。采用 VIA 封装的 DCM 模块可利用集成的 EMI 滤波、精确的稳压输出和 PM 母线控制接口（参考二次侧地）提供更高级的功能。
筛选产品
0 个产品
Viewing
of
###
25
of
| 型号 | Datasheet | 输入电压 (V) | 输出电压 (V) | 功率 (W) | 控制接口 | 优化 | 安装方式 | 温度 | Dimensions mm | Dimensions in. | 封装 | 加入购物车/查看详情 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 3.3 (2.97 - 3.63) |
功率 (W): 120.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 3.3 (2.97 - 3.63) |
功率 (W): 120.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 5.0 (4.0 - 5.5) |
功率 (W): 180.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封装: 3414 VIA |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 5.0 (4.0 - 5.5) |
功率 (W): 180.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 5.0 (4.0 - 5.5) |
功率 (W): 180.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 12.0 (7.2 - 13.2) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封装: 3414 VIA |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 12.0 (7.2 - 13.2) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 12.0 (7.2 - 13.2) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 15.0 (9.0 - 16.5) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封装: 3414 VIA |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 15.0 (9.0 - 16.5) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 15.0 (9.0 - 16.5) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 24.0 (14.4 - 26.4) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封装: 3414 VIA |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 24.0 (14.4 - 26.4) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 24.0 (14.4 - 26.4) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 28.0 (16.8 - 30.8) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -20 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封装: 3414 VIA |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 28.0 (22.0 - 30.8) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 28.0 (22.0 - 30.8) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 48.0 (28.8 - 52.8) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -40 to 125°C |
Dimensions mm: 85.90 x 35.50 x 9.40mm |
Dimensions in.: 3.380 x 1.400 x 0.370in |
封装: 3414 VIA |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 48.0 (28.8 - 52.8) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 28.0 (16.0 - 50.0) |
输出电压 (V): 48.0 (28.8 - 52.8) |
功率 (W): 320.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 3.3 (2.97 - 3.63) |
功率 (W): 80.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 3.3 (2.97 - 3.63) |
功率 (W): 80.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 5.0 (3.5 - 5.5) |
功率 (W): 80.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 5.0 (3.5 - 5.5) |
功率 (W): 80.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 12.0 (7.2 - 13.2) |
功率 (W): 60.0 |
控制接口: Analog |
优化: Array/
Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封装: 2322 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 12.0 (7.2 - 13.2) |
功率 (W): 160.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 12.0 (7.2 - 13.2) |
功率 (W): 160.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 15.0 (9.0 - 16.5) |
功率 (W): 60.0 |
控制接口: Analog |
优化: Array/
Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封装: 2322 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 15.0 (9.0 - 16.5) |
功率 (W): 160.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 15.0 (9.0 - 16.5) |
功率 (W): 160.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 24.0 (14.4 - 26.4) |
功率 (W): 60.0 |
控制接口: Analog |
优化: Array/
Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封装: 2322 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 24.0 (14.4 - 26.4) |
功率 (W): 160.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 28.0 (16.8 - 30.8) |
功率 (W): 60.0 |
控制接口: Analog |
优化: Array/
Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封装: 2322 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 28.0 (16.8 - 30.8) |
功率 (W): 160.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 28.0 (16.8 - 30.8) |
功率 (W): 160.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 48.0 (28.8 - 52.8) |
功率 (W): 60.0 |
控制接口: Analog |
优化: Array/
Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 24.84 x 22.80 x 7.21mm |
Dimensions in.: 0.978 x 0.898 x 0.284in |
封装: 2322 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 48.0 (28.8 - 52.8) |
功率 (W): 160.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 30.0 (9.0 - 50.0) |
输出电压 (V): 48.0 (28.8 - 52.8) |
功率 (W): 160.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 38.72 x 22.80 x 7.21mm |
Dimensions in.: 1.524 x 0.898 x 0.284in |
封装: 3623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 3.3 (2.97 - 3.63) |
功率 (W): 150.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 3.3 (2.97 - 3.63) |
功率 (W): 150.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 5.0 (4.0 - 5.5) |
功率 (W): 250.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -40 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封装: 3714 VIA |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 5.0 (4.0 - 5.5) |
功率 (W): 250.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 5.0 (4.0 - 5.5) |
功率 (W): 250.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 12.0 (7.2 - 13.2) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封装: 3714 VIA |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 12.0 (7.2 - 13.2) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 12.0 (7.2 - 13.2) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 15.0 (9.0 - 16.5) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -55 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封装: 3714 VIA |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 15.0 (9.0 - 16.5) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 15.0 (9.0 - 16.5) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 24.0 (14.4 - 26.4) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封装: 3714 VIA |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 24.0 (14.4 - 26.4) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 24.0 (14.4 - 26.4) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 28.0 (16.8 - 30.8) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Chassis Mount |
温度: -20 to 125°C |
Dimensions mm: 95.10 x 35.50 x 9.40mm |
Dimensions in.: 3.750 x 1.400 x 0.370in |
封装: 3714 VIA |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 28.0 (16.8 - 30.8) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 28.0 (16.8 - 30.8) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 28.0 (16.8 - 30.8) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 48.0 (28.8 - 52.8) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Standalone |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (160.0 - 420.0) |
输出电压 (V): 48.0 (28.8 - 52.8) |
功率 (W): 500.0 |
控制接口: Analog |
优化: Array |
安装方式: Through Hole |
温度: -40 to 125°C |
Dimensions mm: 47.91 x 22.80 x 7.21mm |
Dimensions in.: 1.886 x 0.898 x 0.284in |
封装: 4623 ChiP |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (180.0 - 400.0) |
输出电压 (V): 28.0 (22.0 - 36.0) |
功率 (W): 1300.0 |
控制接口: PM Bus |
优化: Array |
安装方式: Chassis Mount |
温度: -40 to 125°C |
Dimensions mm: 141.43 x 35.54 x 9.40mm |
Dimensions in.: 5.570 x 1.400 x 0.370in |
封装: 5614 VIA |
View Details | ||
| 型号: | 输入电压 (V): 270.0 (180.0 - 400.0) |
输出电压 (V): 28.0 (22.0 - 36.0) |
功率 (W): 1300.0 |
控制接口: Analog |
优化: Array |
安装方式: Chassis Mount |
温度: -40 to 125°C |
Dimensions mm: 141.43 x 35.54 x 9.40mm |
Dimensions in.: 5.570 x 1.400 x 0.370in |
封装: 5614 VIA |
View Details | ||
Power System Designer
采用电源系统设计工具快速查找产品Watch demo video
Output
Min output:
Minimum output:
Nom output:
Nominal output:
Max output:
Maximum output:
特点与优势
特点与优势
高达 1300W，46.4A 连续
高达 96% 峰值效率
功率密度高达 1032W/in3
OV、OC、UV、短路和热保护
资源
Resources section
4623 ChiP
3714 VIA 3414 VIA 5614 VIA
- cURus – UL 60950-1, CSA 60950-1 »
- cTÜVus – EN 60950-1, UL 60950-1, CSA 60950-1
- CE 标志 – 低电压指令 (2014/35/EC) 和 RoHS 修订指令 (2011/65/EU)
- CB 认证 – IEC 60950-1
- cURus – UL 60950-1, CSA 60950-1 »
- cTÜVus – EN 60950-1, UL 60950-1, CSA 60950-1
- CE 标志 – 低电压指令 (2014/65/EC) 和 RoHS 修订指令 (2011/65/EU)
- CB 认证 – IEC 60950-1
3714 VIA 3414 VIA 5614 VIA
加州居民请参考加州 65 号提案的内容
- 2322 ChiP 通孔产品 3D 模型图
IGS STP - 3623 ChiP 通孔产品 3D 模型图
IGS STP - 4623 ChiP 通孔产品 3D 模型图
IGS STP - 3414 VIA DCM 带通讯的底盘安装外形图
IGS STP - 3414 VIA DCM 带通讯的通孔短引脚外形图
IGS STP - 3414 VIA DCM 带通讯的通孔短长引脚外形图
IGS STP - 3714 VIA DCM 带通讯的底盘安装外形图
IGS STP - 3714 VIA DCM 带通讯的通孔短引脚外形图
IGS STP - 3714 VIA DCM 带通讯的通孔短长引脚外形图
IGS STP - 5614 VIA DCM 带通讯的底盘安装外形图
IGS STP - 5614 VIA DCM 带通讯的通孔短引脚外形图
IGS STP - 5614 VIA DCM 带通讯的通孔短长引脚外形图
IGS STP
Promo Component
在资源库中查看更多文档、视频和案例研究
