Instrumentation

The lowest noise and best thermal management for test and measurement systems

モジュールで構成する
スケーラブルな電力供給

優れた熱マネジメント

低ノイズ

高電力密度

Space constraints limit performance

Maintaining signal integrity

It is vital to the operation of this specialized instrumentation that power delivery networks (PDNs) do not contribute to parasitic noise. Unwanted noise introduced into the system from external sources can compromise or degrade signal integrity rendering the resultant test results useless.

Managing excessive heat

Test and measurement devices routinely run warm due to the compact nature of the equipment and operating environment. Too much localized heat can reduce the effectiveness of the equipment and if it persists unchecked it could result in premature catastrophic failure of the equipment.

Best in-class power density and efficiency

High performance with low noise

Vicor high-performance, high-density power modules are ideal for space constrained instrumentation systems. Patented power system architectures, like Vicor Factorized Power Architecture (FPA), are inherently low-noise and will not impact sensitive measurements.

Efficient thermal management

The high-efficiency modules reduce losses that generate heat, and the planar form of the modules lend themselves to cost-effective and efficient thermal management. This combination allows modules to fit into tight spaces without the need for excessive and expensive cooling solutions.

電力供給ネットワーク (PDN)

The sample PDN shown was designed to use an intermediate 48V bus for better efficiency from 48V to the point-of-load. When designed in parallel, the Vicor DCM isolated, regulated DC-DC converter modules deliver over 600W of power at 92.7% efficiency at full load. In the same PDN, the Vicor VTM and NBM (isolated and non-isolated) fixed-ratio DC-DC modules transform 48V to a large variety of point-of-load requirements up to 12V at 96% efficiency. Inherently low noise Sine Amplitude Converter (SAC) topology and advanced packaging technology – combined with planar magnetics and a low profile – greatly simplify and improve thermal management.
